Model - Baja® Wrangler® 2

Model Number - BA400

• Maximum Speed - Up to 11 mph at 450 lbs.; Up to 11.4 mph at 200 lbs.

• Range Per Charge - Up to 13.2 miles at 450 lbs. (75AH);

                                     - Up to 20.2 miles at 200 lbs. (75AH);
                                     - Up to 17.4 miles at 450 lbs. (100 AH);
                                     - Up to 26.6 miles at 200 lbs. (100AH)

• Suspension - Front and rear (CTS Suspension)

• Weight Capacity - Up to 450 lbs.

• Highest Ground Clearance - 8.25" at mid-frame

• Lowest Ground Clearance - 5.5" at motor

• Turning Radius (4-Wheel) - 94.75"

• Overall Length - 61.25"

• Overall Width - 32.5"

• Standard Seating - Type: Limited Recline,Memory Foam Seat with Sliders

• Seat-to-Ground Height - 29"-30.5"

• Seat-to-Deck Height - 20.5"-22"

• Front Tires - 14.5" Tubeless

• Rear Tires - 14.5" Tubeless

• Battery Requirements - Type: (2) 75AH; (2) optional 100 AH

• Weight: 75AH- 48 lbs.; 100 AH- 60.5 lbs.

• Battery Charger: Off-board, 8 amp

• Total Weight Without Batteries - 274 lbs.

• Heaviest Piece when Disassembled - 219 lbs. (unit does not disassemble) without seat and batteries

• Total Product Weight (Standard) - 370 lbs. (75 AH); 395 lbs. (100 AH)

• Drive System - 24- volt DC motor, rear-wheel drive, dual in-line

• Braking System - Regenerative and electromechanical​

​​

Medicare HCPCS

Non-Medical Device



Warranty

Frame: Lifetime limited
Drivetrain: 2-year limited
Electronics: 2-year limited
Battery: 6-months
